YL Two Value Capacitor Motor

1 Hp Single Phase Induction Motor

1 Hp Single Phase Induction Motor

Quick Details Packaging & Delivery Capacitor motor Specifications: (1) Frame size: 71-132 (2) Rated power: 0.37-7.5kW (3) Rated voltage: 110 - 120V, 200 - 240V (4) Frequency: 50Hz, 60Hz,50Hz/Hz (5) Protection class: IP44 (6) Insulation class: B, F (7) Materials: cast iron, aluminum (8) EFF:...
Send InquiryChat Now

Quick Details

Place of Origin: Zhejiang, China (Mainland)Brand Name: DFDModel Number: YL
Certificate:CE,CCC,RoHS,ISO9001,IE1,IE2Usage: UniversalProtect Feature: Totally Enclosed,Waterproof
Function: DrivingStructure: Asynchronous MotorPhase: Single-phase
Speed: Constant SpeedShape: TubularPower: AC


Packaging & Delivery

Packaging DetailsPacked for export requirement:
Frame 71-90: Cartons; Frame 100-132: Wooden boxes
Delivery Time30-35 days after receiving downpayment


Capacitor motor

Specifications:

1) Frame size: 71-132
2) Rated power: 0.37-7.5kW
3) Rated voltage: 110 - 120V, 200 - 240V
4) Frequency: 50Hz, 60Hz,50Hz/60Hz
5) Protection class: IP44, IP54
6) Insulation class: B, F
7) Materials: cast iron, aluminum
8) EFF: EFF2, EFF1
9) Poles: 2, 4, 6
10) Cooling method: IC411 (total-enclosed fan-cooled type)
11) Mounting types: IMB3, IMB35, IMB5, IMB14, IMB34
12) Operating mode: S1
13) Ambient temperature: -40°C< θ <40°C
14) The altitude should be lower than 1,000m above the sea level
15) Relative humidity: not higher than 90%
16) Special motors can be designed according to customers'requirements
17) Export markets: Europe, North America, the Middle East, Africa, Southeast Asia,East Asia, South America


Inner packing:Foam box
Outer packing: Wooden box


Conveyance:
Qty/20' FCL: 1000pcs





Certificate:
